Insulated WindStorm™ Door – 436
Model 436
WindStorm™ Commercial Sectional Model 436 is a insulated door featuring FBC and TDI certifications for static pressures and impact with a R-value of 7.64. Constructed of nominal 24-gauge steel and designed with 4” horizontal struts to enhance door strength.
Overview
Construction
| Product Specifications | |
|---|---|
| Standard Max Width | 20'2" (7341 mm) |
| Standard Max Height | 16'1" (7924 mm) |
| Section thickness | 2" (51 mm) |
| Exterior steel | Nominal 24-gauge |
| Exterior surface | Ribbed |
| Struts | 4" horizontal strut (doors over 10'2" wide) |
| Interior color | White |
| Standard springs | 10,000 cycles |
| Standard track | 2" (51 mm) |
| Joint profile | Tongue-and-groove |
| Wind Load | Certified to meet FBC and TDI wind load requirements |
Warranty
- 1 year limited
Options
Ribbed Panel
Exterior Colors
White
Brown
Vision Lites
Full-view Lites
- Chain hoist operation
- Motor operation
- High Cycle Springs - 25k, 50k, 100k
- 3” track option
- Solid shafts
- Perimeter weather seal
- Broken cable devices
- Safety edges
- Safety photo eyes
- Impact glazing 12” x 10”
- Security locks
- Exhaust ports
Brochures
Documents
